Push to Talk (PTT) over Cellular RM-1560 - Dual 4G LTE/Analog Radio

Long range wireless walkie-talkie communicator with 4G LTE capacity. The RM-1560 is equipped for DUAL mode with nationwide and worldwide cellular connectivity that has no range limit and as an analog walkie talkie radio. IP66 certified this field device is waterproof, shock and dust proof. A go-anywhere companion.
Manufacturer: REAL Mobile
Delivery date: 2 weeks
*

Use this space to send us any special request or instructions.

Old price: $219.00
$149.00
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options

Long range portable walkie-talkie communicator. The RM-1560 is equipped for nationwide and global cellular connectivity with 4G LTE and has no range limit. The analog radio functionality connects with conventional walkie talkies as well as providing a back-up to the cellular connection.

IP66 certified this field device is waterproof, shock and dust proof.


A go-anywhere companion.


Have instant communication with all your field personnel and with no range limit.

With the REAL Mobile multi-carrier 4G LTE SIM this communicator goes Global!


Add the Administrative Dispatcher portal giving you access in REAL time with your field crew.

See where everyone is with your on-screen map, broadcast, single call and more ...

Long range portable wireless walkie-talkie

 Monthly nationwide service for only $17.00

(Dispatcher console for only $10.00 monthly)

Specification

Parameter

Model No

RM-1560

Dimension

126mmx61mmx38mm

Weight

340g

Working Temperature

-20℃~+60℃

Working Voltage

DC 7.5v

Working Current

250Ma @ UTMS 2100/900

Peak Current

0.8A

Working Range

UMTS/HSDPA 850/1900/2100

GSM/GPRS/EDGE B3, B8

LTE FDD:B2,B4,B5,B12,B17

Maximum Output Power

WCDMA 900/2100MHz:Power Class 3(+24dBm +2.5Bm/-1.5dBm)

GSM/GPRS850/900MHz:Power Class(+33dBm +2.5Bm/-0.5dBm)

GSM/GPRS1800/1900MHz:Power Class(+30dBm +2.5Bm/-0.5dBm)

Receiving Sensitivity

WCDMA 900: ≤-108dBm

WCDMA 2100: ≤-109dBm

GSM 850/900/1800/1900: ≤-106dBm

GPS

GPS Posotioning,1.57542GHz

Batteru

3000 mAh

Sensitivity

Catch -144dBm,Track-159dBm

Data Speed Rate

GSM CS:UL 9.6kpbs/DL9.6kpbs

GPRS: Muiti-solt Class 10

EDGE: Muiti-solt Class 10

WCDMA CS:UL 64kpbs/DL 64kpbs

WCDMA CS:UL 64kpbs/DL 64kpbs

WCDMA PS:UL 384kpbs/DL 384kpbs

Protocol

HSDPA/WCDMA/EDGE/GPRS/GSM

Battery*1 , Antenna*1,  Changer*1 , Belt clip*1 ,Hand strap*1

Channel Capacity128 (400-520MHZ)
Channel spacing25kHz/12.5kHz
Operating voltageDC 7.5v
frequency rangeUHF
working modechannel/frequency/channel + frequency
antenna impedance50 ohms
operating temperature-20c - +60c
fm modeFM
frequency stability+- /-2.5ppm
reference sensitivity> -121dBm
adjacent path sensitivity>65dB
audio response<=2dB & >= -10dB
rated audio power1000mW
receive signal-to-noise ratio>=45dB
audio distortion<=5%
co-channel suppression>= 8dB
Products specifications
Attribute nameAttribute value
ModesGSM 850/1900
4GLTE FDD:B2,B4,B5,B12,B17
3G Data850/1900
FunctionsGroup/Private/All Call Function
Battery Life3000 mAh Lithium Battery - 15 - 22 hours standby
Dimension126mmx61mmx38mm
Weight340g
ChargingMicro USB Charge
Water ResistantIP66
GPSGPS Posotioning,1.57542GHz ;
